SHANK
CUTTERS
S O M T A P 1 2 C A T A L O G U E
118
Shank Cutter Terminology
OVERALL LENGTH
CUTTING
LENGTH
CUTTING
DIAMETER
SHANK
DIAMETER
END
TEETH
HELIX
ANGLE
THREADED
SHANK
TOLERANCE h8
FLATTED
SHANK
TOLERANCE h6
DIN 1835 - B
PLAIN SHANK
TOLERANCE
h7
AXIAL GASH
ANGLE
END TEETH
PRIMARY
CLEARANCE
END TEETH
SECONDARY
CLEARANCE
LAND
RADIAL
RAKE
PERIPHERAL
PRIMARY
CLEARANCE
PERIPHERAL
SECONDARY
CLEARANCE
END TEETH
CONCAVITY
OVER
CENTRE
TOOTH
GASH
ANGLE
END TEETH
GASH
THREADED
SHANK:
ALL DIAMETERS
20 TPI
WHITWORTH
FORM
2-FLUTE
3-FLUTE
4-FLUTE
CENTRE
CUT
4-FLUTE
CENTRE
HOLE
MULTI-FLUTE
